项次
|
材料代号
|
名称
|
Name
|
规格
|
|
1
|
2001022025
|
第一轴
|
The first shaft
|
1701126-11F58
|
|
2
|
2038022002
|
一轴锥体
|
The first shaft cone
|
1701127-B1
|
|
3
|
3032001004
|
轴用弹性挡圈
|
Circlip for shaft
|
Q43135(1.5厚)
|
|
4
|
3022001011
|
二轴后轴承
|
Second shaft rear bearing
|
6307N
|
|
5
|
3032001015
|
轴用压扁钢丝挡圈
|
|
Q43380
|
|
6
|
3022006002
|
滚柱
|
Pin roller
|
1701334-B1
|
|
7
|
3032004002
|
孔用弹性挡圈
|
Circlip for hole
|
1701331-B1(PTJ520-1701332B1)
|
|
8
|
3032001046
|
轴用压扁钢丝挡圈
|
|
Q43348
|
|
9
|
2012022004
|
第二轴
|
The second shaft
|
JD525-1701301A
|
|
10
|
2019022017
|
二轴一档齿轮
|
Second shaft 1-speed gear
|
|
|
11
|
2043022005
|
同步器锥体-第二三速
|
Synchronizer Cone-2、3speed
|
1701304-B1B2
|
|
12
|
2018022019
|
二轴二档齿轮
|
Second shaft 2-speed gear
|
1701302-11B1
|
|
13
|
2043022005
|
同步器锥体-第二三速
|
Synchronizer Cone-2、3speed
|
1701304-B1B2
|
|
14
|
2017022007
|
二轴三档齿轮
|
Second shaft 3-speed gear
|
1701313-11
|
|
15
|
2043022005
|
同步器锥体-第二三速
|
Synchronizer Cone-2、3speed
|
1701304-B1B2
|
|
16
|
2015022012
|
主轴五档齿轮
|
First shaft 5-speed gear
|
1701318-11C1
|
|
17
|
2038022002
|
一轴锥体
|
The first shaft cone
|
1701127-B1
|
|
18
|
2020022009
|
倒车齿轮
|
Reverse gear
|
1701338-11B1
|
|
19
|
3014008002
|
止推垫
|
Thrust washer
|
JD525-1701341A
|
|
20
|
3015003002
|
钢球
|
Steel ball
|
Q966040
|
|
21
|
3013005005
|
套环-二轴三档齿轮
|
Ring-second shaft 3-speed gear
|
PTJ525-1701366-11
|
|
22
|
3013005006
|
锁环-四档齿轮座
|
Lock ring-4-speed gear
|
PTJ525-1701333-11
|
|
23
|
3013005007
|
止推垫片-二轴三档齿轮
|
Thrust washer
|
PTJ525-1701364-11
|
|
24
|
3022005041
|
滚针轴承
|
Needle bearing
|
RK384428
|
|
25
|
3032003012
|
卡环
|
Snap ring
|
1701317-B1
|
|
26
|
3022005042
|
滚针轴承
|
Needle bearing
|
RK455031
|
|
27
|
3022005043
|
滚针轴承
|
Needle bearing
|
RK455029
|
|
28
|
3013003009
|
轴承座圈
|
Bearing race
|
JD525-1701316A
|
|
29
|
3040002008
|
一倒档同步器
|
1-speed/Reverse gear synchronizer
|
1701360-B1B1
|
|
30
|
3040002012
|
同步器总成-第二、三速
|
2/3speed gear Synchronizer assembly
|
JD525-1701330
|
|
31
|
3040002013
|
同步器总成-第四、五速
|
4/5-speed gear synchronizer assembly
|
JD525-1701355
|
|
32
|
3022003001
|
滚柱推力轴承
|
Thrust roller bearing
|
30206
|
|
33
|
2009022002
|
中间轴常啮合齿轮
|
Intermediate shaft mesh gear
|
1701212-11X1
|
|
34
|
2007022001
|
中间轴五档齿轮
|
Intermediate shaft 5-speed gear
|
1701213-11C1
|
|
35
|
2010022001
|
中间轴二/三档齿轮
|
Intermediate shaft 2、3-speed gear
|
1701214-11B1
|
|
36
|
2002022001
|
中间轴
|
Intermediate shaft
|
1701211-11X1
|
|
37
|
3022003002
|
向心推力轴承
|
Centripetal thrust bearing
|
32206
|
|
38
|
3005017002
|
换挡拨块
|
|
1702027-B1
|
|
39
|
3006001001
|
波口弹性销Q5280635
|
Wave mouth elastic pin Q5280635
|
1702089-B1
|
|
40
|
3007002017
|
弹性圆柱销Q5280435
|
Elastic cylindrical pin Q5280435
|
1702039-B1
|
|
41
|
3005006007
|
变速叉-第四、五速
|
Selector fork-4、5-speed
|
JD525-1702023
|
|
42
|
3005016002
|
互锁板
|
|
JD525-1702033
|
|
43
|
3005004003
|
变速叉-第二、三速
|
Selector fork-2、3-speed
|
JD525-1702024B1
|
|
44
|
3004002007
|
变速叉杆-第一、倒速
|
Selector fork-1-speed、reverse speed
|
JD525-1702037
|
|
45
|
3007002013
|
弹性圆柱销
|
Elastic cylindrical pin
|
Q5280324
|
|
46
|
3007002012
|
弹性圆柱销
|
Elastic cylindrical pin
|
Q5280524
|
|
47
|
3005002004
|
变速叉-第一速及倒档
|
Selector fork-1-speed、reverse speed
|
JD525-1702026
|
|
48
|
3004005002
|
变速叉轴
|
Transmission fork shaft
|
JD525-1702021
|
|
49
|
3007002018
|
换档销Q5210835
|
Shift pin Q5210835
|
1702022-B1
|
|
50
|
2806022005
|
顶盖总成
|
Top cover assembly
|
JD525ZXDG-003
|
|
51
|
3030001051
|
六角螺栓
|
Hexagon bolt
|
Q150B0820彩
|
|
52
|
3011003012
|
弹簧垫圈（彩）
|
Spring washer (color)
|
Q40308彩锌
|
|
53
|
3030006007
|
双头螺栓
|
Double armed bolt
|
Q1210825彩锌
|
|
54
|
3031001013
|
螺母
|
Nut
|
Q341B08彩锌
|
|
55
|
3030006004
|
双头螺栓
|
Double armed bolt
|
JDB1211248彩锌
|
|
56
|
3011003016
|
弹簧垫圈（彩）
|
Spring washer (color)
|
Q40312彩锌
|
|
57
|
3031001012
|
螺母
|
Nut
|
Q341B12彩锌
|
|
58
|
3030008002
|
加油塞总成
|
Plug assembly
|
LG520-1701013B1
|
|
59
|
3030008003
|
放油塞总成
|
Plug assembly
|
LG520-1701020B1
|
|
60
|
3011004003
|
组合垫圈
|
Combined washer
|
LG520-1701015B1
|
|
61
|
3011003013
|
弹簧垫圈
|
Spring washer
|
Q40310彩锌
|
|
62
|
3030001034
|
六角螺栓（彩）
|
Hexagon bolt (color)
|
Q150B1016彩锌
|
|
63
|
3025001004
|
取力器孔盖板
|
Power takeoff hole cover
|
JD520-0091
|
|
64
|
3030006003
|
双头螺栓
|
Double armed bolt
|
JDB1211238彩锌
|
|
65
|
3009002014
|
吊环
|
Ring
|
PTJ5-20-1701018K28
|
|
66
|
3011003017
|
弹簧垫圈（彩）
|
Spring washer (color)
|
Q40306彩锌
|
|
67
|
3030001054
|
螺栓
|
Bolt
|
Q150B0616彩
|
|
68
|
3028005028
|
锁片-软轴接头
|
Lock plate
|
1701363-B1
|
|
69
|
3001003003
|
O形圈
|
O ring
|
25.2*3.1
|
|
70
|
3034006003
|
里程表从动齿轮
|
Odometer driven gear
|
1701346-B2
|
|
71
|
3035004001
|
里程表软接头
|
Odometer soft joint
|
1701361-B1C1
|
|
72
|
3030001045
|
六角螺栓（彩）
|
Hexagon bolt (color)
|
Q150B0825彩锌
|
|
73
|
3019001018
|
一轴轴承盖
|
First shaft bearing
|
JD525C-1701141
|
|
74
|
3023001006
|
骨架油封
|
framework oil seal
|
30*45*10TC
|
|
75
|
3029001005
|
前轴承盖垫密片
|
Front bearing
|
1701142-B1
|
|
76
|
3003002003
|
球头螺钉子
|
|
JD525-1600011
|
|
77
|
3045004002
|
离合器罩壳
|
Clutch box
|
JD525L-0021A2
|
|
78
|
3019003007
|
中间轴端盖
|
The intermediate shaft
|
1701216-B1B1
|
|
79
|
3032004003
|
孔用弹性挡圈
|
Circlip For Hole
|
Q43062
|
|
80
|
3017010004
|
前壳体
|
Front case
|
1701011-11K48
|
|
81
|
3017008003
|
后壳体
|
Rear case
|
1701012-K2
|
|
82
|
3027005001
|
倒档轴
|
Reverse shaft
|
1701413-B1
|
|
83
|
2011022015
|
倒档惰轮及衬套总成
|
Reverse idler and bushing assembly
|
JD525-1701410A
|
|
84
|
3025002002
|
惰轮轴盖板
|
Idler shaft cover plate
|
1701417-B1
|
|
85
|
3030001052
|
螺栓
|
Bolt
|
Q150B0816彩
|
|
86
|
3028005027
|
惰轮轴锁片
|
Idler shaft locking plate
|
1701416-B1
|
|
87
|
3028005024
|
中间轴后轴承调整垫片
|
The intermediate shaft rear bearing gasket
|
1701221-B1
|
|
88
|
3028005025
|
中间轴后轴承调整垫片
|
The intermediate shaft rear bearing gasket
|
1701222-B1
|
|
89
|
3028005026
|
中间轴后轴承调整垫片
|
The intermediate shaft rear bearing gasket
|
1701223-B1
|
|
90
|
3019005012
|
二轴后轴承盖
|
Second shaft rear bearing cover
|
JD525-1701356B1
|
|
91
|
3032001015
|
轴用压扁钢丝挡圈
|
|
Q43380
|
|
92
|
3013002021
|
里程表主动齿轮隔套
|
Odometer driving gear bush
|
1701343-K68A
|
|
93
|
3033007001
|
里程表主动齿轮
|
Odometer driving gear
|
1701344-B1B1
|
|
94
|
3047007008
|
挡油圈
|
Oil deflector
|
1701348-B1
|
|
95
|
3022001019
|
轴承
|
Bearing
|
6207E
|
|
96
|
3023002013
|
二轴油封
|
Second shaft oil seal
|
45*72*12TC
|
|
97
|
3021006002
|
突缘
|
Flange
|
JD525-1701350B1
|
|
98
|
3031004002
|
锁紧螺母
|
jam nut
|
1700C-170A
|
|
99
|
3030005007
|
突缘螺栓
|
Flange bolt
|
JD530-172FT
|
|
100
|
3039001002
|
叉轴孔堵盖
|
|
1702036-B1
|
|
101
|
3015001004
|
钢球
|
Steel ball
|
Q966080
|
|
102
|
3008003025
|
自锁弹簧
|
Lock spring
|
1702029-B1A3
|
|
103
|
3030007001
|
螺栓
|
Bolt
|
LG515Q-1701372
|
|
104
|
3042005007
|
倒车灯开关
|
Reversing light switch
|
WK-34
|
|
105
|
3005015001
|
变速叉限位块
|
|
1702034Y
|
|
106
|
3029017001
|
换档垫密片
|
|
JD520-0074
|
|
107
|
3043001001
|
常开通气塞
|
Air plug
|
1702091-B1
|
|
108
|
2807022002
|
分离轴承座总成
|
Release bearing assembly
|
1602130-525
|
|
109
|
3022004003
|
分离轴承
|
Release bearing
|
996911K3
|
|
110
|
3008001005
|
分离轴承拉簧
|
Release bearing spring
|
JD525-1600021
|
|
111
|
3046006006
|
分离拨叉
|
Release fork
|
JD525-1670011
|
|
112
|
3047006015
|
橡胶防尘罩
|
Rubber dust cover
|
JD5T28EL-0012
|
|
113
|
3047006016
|
拨叉防尘罩
|
Fork dust cover
|
JD5T28EL-0013
|
|
114
|
3003002004
|
十字槽盘头螺钉
|
Cross recess head screw
|
Q2140408
|
|
115
|
3047017001
|
里程表传感器
|
Odometer sensor
|
WK-53
|
|
116
|
3029006003
|
倒档惰轮盖板垫密片
|
|
1701418-B1
|
